11 - 58 DS4308/DS4308P Digital Scanner Product Reference Guide

Codabar Upper or Lower Case Start/Stop Characters Detection

Parameter # 855 (SSI # F2h 57h)

Select whether to detect upper case or lower case Codabar start/stop characters.

Lower Case

(1)

*Upper Case

(0)
