Zebra DS4308 Product Reference Guide

12 - 6 DS4308/DS4308P Digital Scanner Product Reference Guide
IDC Symbology
Parameter Name: DocCap_SYMBOLOGY
Parameter # 655 (SSI # F1h 8Fh)
Select the bar code type(s) to use when Document Capture mode is not set to Off. To enable more than one
symbology at a time, simply add the values together. For example, to enable PDF417, Data Matrix, and Code
39 write a value of 98 (32 + 64 + 2).
Scan the bar code below, followed by three bar codes from Appendix G, Numeric Bar Codes in the range of
000 to 255 decimal. The default is 001.
Table 12-2 IDC Symbologies
Symbology Value (Decimal)
Code 128 1
Code 39 2
I 2 of 5 4
D 2 of 5 8
Codabar 16
PD 417 32
Data Matrix 64
EAN 128 128
IDC Symbology
