Maintenance & Technical Specifications 3 - 7
Technical Specifications
Table 3-2
Technical Specifications
Item Description
Physical Characteristics
Dimensions
DS4308
DS4308P
6.48 in. H x 3.86 in. L x 2.64 in. W
(16.5 cm H x 9.8 cm L x 6.7 cm W)
8.15 in. H x 5.18 in. L x 3.74 in. W
(20.7 cm H x 13.15 cm L x 9.5 cm W)
Weight
(without cable)
DS4308
DS4308P
5.71 oz. (162 g)
10.6 oz. (300 g)
Power 5 VDC +/- 10% @ 360 mA (RMS typical)
Performance Characteristics
Light Source Aiming pattern: 617 nm LED
Illumination: 660 nm LEDs
Field of View
(Vertical x Horizontal)
36º (H) x 22.5º (V)
Roll
Pitch
Yaw
0 - 360º
+/- 65º or greater
+/- 60º or greater
Symbology Decode Capability
1D UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon
Extended Code, Code 128, GS1-128, ISBT 128, ISBT Concatenation, Code 39,
Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code 11, Interleaved 2
of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, Matrix 2 of 5, Korean 3 of 5,
GS1 DataBar variants
2D PDF417, MicroPDF417, Composite Codes, TLC-39, Data Matrix, GS1 Data
Matrix, Maxicode, QR Code, GS1 QR Code, MicroQR, Aztec, Han Xin
Postal US Postnet, US Planet, UK Postal, Japan Postal, Australia Post, Royal Mail 4
State Customer, KIX Code (Dutch), UPU 4 State Postal FICS (Post US4), USPS
4 State Postal (Post US3), Mailmark
Typical Working Distance See
Decode Ranges on page 2-13
.
Motion Tolerances Up to 30 in. (76.2) cm per second
