Zebra DS4308 Product Reference Guide

Data Capture 2 - 13
Decode Ranges
Table 2-3 DS4308 Decode Ranges
Bar Code
Type
Symbol
Density
DS4308-SR
Typical Working Ranges
DS4308-HD
Typical Working Ranges
DS4308-XD
Typical Working Ranges
Near
(in / cm)
Far
(in / cm)
Near
(in / cm)
Far
(in / cm)
Near
(in / cm)
Far
(in / cm)
Code 128 2.0 mil N/A N/A N/A N/A 0.6 / 1.5 3.0 / 7.6
3.0 mil N/A N/A 1.0 / 2.5 3.0 / 7.6 0.4 / 1.0 3.3 / 8.4
Code 39 2.0 mil N/A N/A N/A N/A 0.5 / 1.3 3.0 / 7.6
3.0 mil 1.5 / 3.8 5.4 / 13.7 0.5 / 1.3 5.8 / 14.6 0.2 / 0.5 3.8 / 9.7
5.0 mil 0.0 / 0.0 11.0 / 27.9 0.0 / 0.0 10.0 / 25.4 0.1 / 0.3 4.7 / 11.9
20.0 mil 0.0 / 0.0 53.0 / 134.6 0.0 / 0.0 30.0 / 76.2 N/A N/A
100% UPC 13.0 mil 0.0 / 0.0 28.0 / 71.1 0.0 / 0.0 16.5 / 41.9 N/A N/A
PDF417 4.0 mil N/A N/A N/A N/A 0.5 / 1.3 3.3 / 8.4
5.0 mil N/A N/A N/A N/A 0.1 / 0.3 3.6 / 9.1
6.6 mil 1.1 / 2.8 8.0 / 20.3 0.2 / 0.5 7.8 / 19.7 0.1 / 0.3 4.1 / 10.4
MicroPDF 4.0 mil N/A N/A 1.0 / 2.5 4.7 / 11.9 N/A N/A
5.0 mil N/A N/A N/A N/A 0.2 / 0.5 3.1 / 7.9
Data Matrix 4 mil N/A N/A N/A N/A 0.7 / 1.8 3.0 / 7.6
5 mil N/A N/A 1.2 / 3.0 3.5 / 8.9 0.4 / 1.0 3.4 / 8.6
7.5 mil N/A N/A 1.0 / 2.5 6.5 / 16.5 N/A N/A
10.0 mil 2.0 / 5.1 9.0 / 22.9 0.8 / 1.9 8.2 / 20.8 0.1 / 0.3 4.6 / 11.7
QR Code 10.0 mil 1.1 / 2.8 8.5 / 21.6 0.0 / 0.0 7.0 / 17.8 0.0 / 0.0 4.5 / 11.4
20.0 mil 0.9 / 2.3 16.2 / 41.1 0.5 / 1.3 11.0 / 27.9 N/A N/A

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
