Zebra DS4308 Product Reference Guide

Intelligent Document Capture 12 - 7
IDC X Coordinate
Parameter Name: DocCap_X
Parameter # 596 (SSI # F4h F1h 54h)
Specify the horizontal offset to the top left corner of the region to capture relative to the center of the bar code.
Negative values move toward the left. This parameter only applies when IDC Operating Mode is set to
Anchored.
Scan the bar code below, followed by four bar codes from Appendix G, Numeric Bar Codes in the range of
+/- 1279. The default is -151. Note that you must use an application to set a negative value.
IDC Y Coordinate
Parameter Name: DocCap_Y
Parameter # 597 (SSI # F4h F1h 55h)
Specify the vertical offset to the top left corner of the region to capture relative to the center of the bar code.
Negative values move toward the top. This parameter only applies when IDC Operating Mode is set to
Anchored.
Scan the bar code below, followed by four bar codes from Appendix G, Numeric Bar Codes in the range of
+/- 1023. The default is -050. Note that you must use an application to set a negative value.
IDC X Coordinate
IDC Y Coordinate

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
