User Preferences & Miscellaneous Options 4 - 35

Illumination Brightness

Parameter # 669 (SSI # F1h 9Dh)

This parameter controls the illumination brightness used during an active decode session and only applies in

hand-held mode (not in presentation mode).

NOTE The default for the DS4308-XD is Low.

*High

(8)

Medium

(4)

Low

(2)
