10 - 6 DS4308/DS4308P Digital Scanner Product Reference Guide

Alternate Numeric Keypad Emulation

This allows emulation of most other country keyboard types not listed in Appendix B, Country Codes in a

Microsoft

operating system environment..

Quick Keypad Emulation

This parameter enables faster keypad emulation where character value sequences are only sent for characters

not found on the keyboard.

NOTE If your keyboard type is not listed in the country code list (see Country Codes on page B-1), disable Quick

Keypad Emulation on page 10-6 and ensure Alternate Numeric Keypad Emulation on page 10-6 is

enabled.

*Enable Alternate Numeric Keypad

Disable Alternate Numeric Keypad

NOTE This option applies only when Alternate Numeric Keypad Emulation is enabled.

*Enable Quick Keypad Emulation

Disable Quick Keypad Emulation
