Zebra DS4308 Product Reference Guide

12 - 12 DS4308/DS4308P Digital Scanner Product Reference Guide
IDC Maximum Text Length
Parameter Name: DocCap_MAX_TEXT
Parameter # 657 (SSI # F1h 91h)
Specify the maximum number of characters encoded in a bar code for the IDC firmware to use it as an
anchored or linked bar code. Set this to zero (the default) to disable all checking and use all bar codes.
Scan the bar code below, followed by two bar codes from Appendix G, Numeric Bar Codes in the range of 00 to
55 decimal. The default is 00.
IDC Captured Image Brighten
Parameter Name: Sig_BRIGHTEN
Parameter # 654 (SSI # F1h 8Eh)
Enable Captured Image Brighten to make image brightness uniform and enhance contrast such that a large
percent of the background pixels is made completely white (a smaller percentage of pixels is made completely
black if the program determines there is no danger of enhancing the contrast of a very bland area).
IDC Maximum Text Length
NOTE This parameter is also used for Signature Capture.
Disable Captured Image Brighten
(0)
*Enable Captured Image Brighten
(1)

Zebra DS4308 Specifications

General

Sealing	IP42
Connectivity	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Decode Capability	1D, 2D, PDF417
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Operating Temperature	32° to 104° F/0° to 40° C
Storage Temperature	-40° to 158° F/-40° to 70° C
Humidity	5% to 95% (non-condensing)
Weight	5.7 oz./161.9 g
Dimensions	6.5 in. H x 2.6 in. W x 3.6 in. D 16.5 cm H x 6.6 cm W x 9.1 cm D
