8 - 8 DS4308/DS4308P Digital Scanner Product Reference Guide

RS-232 Host Types (continued)

The CUTE host disables all parameter scanning, including Set Defaults. If you inadvertently select CUTE,

scan *Enable Parameter Bar Code Scanning (1) on page 4-6, then change the host selection.

OPOS/JPOS

Fujitsu RS-232

CUTE

DS4308/DS4308P Product Reference Guide1
- Warranty5
- Revision History6
Table of Contents7
