10 - 18
DS4308/DS4308P Digita
l Scanner Product Reference Guide
3084
GUI T
3085
GUI U
3086
GUI V
3087
GUI W
3088
GUI X
3089
GUI Y
3090
GUI Z
T
able 10-5
Keyboard Wedge F K
ey Charac
ter Set
F Keys
Keystroke
5001
F1
5002
F2
5003
F3
5004
F4
5005
F5
5006
F6
5007
F7
5008
F8
5009
F9
5010
F10
501
1
F1
1
5012
F12
5013
F13
5014
F14
5015
F15
5016
F16
5017
F17
5018
F18
5019
F19
5020
F20
5021
F21
T
able 10-4
Keyboard Wedg
e GUI Key Character Set (Continued)
GUI Keys
Keystrokes
221
223
Table of Contents
DS4308/DS4308P Product Reference Guide
1
Warranty
5
Revision History
6
Table of Contents
7
About This Guide
19
Introduction
19
Configurations
19
Chapter Descriptions
20
Notational Conventions
21
Related Documents
22
Service Information
22
Getting Started
23
Introduction
23
Interfaces
24
Unpacking
24
Setting Up the Digital Scanner
25
Installing the Interface Cable
25
Removing the Interface Cable
26
Connecting Power (if required)
26
Configuring the Digital Scanner
26
Accessories
27
Data Capture
29
Introduction
29
Beeper Definitions
30
LED Definitions
32
Scanning
34
Scanning in Hands-Free (Presentation) Mode - DS4308
34
Scanning in Hands-Free (Presentation) Mode - DS4308P
37
Scanning in Hand-Held Mode
39
Aiming
39
Decode Ranges
41
Maintenance & Technical Specifications
43
Introduction
43
Maintenance
43
General Scanner Maintenance
43
Healthcare Scanner Maintenance
43
Troubleshooting
45
Report Software Version Bar Code
48
Technical Specifications
49
Digital Scanner Signal Descriptions
51
User Preferences & Miscellaneous Options
53
Introduction
53
Scanning Sequence Examples
54
Errors While Scanning
54
User Preferences/Miscellaneous Options Parameter Defaults
54
User Preferences
57
Default Parameters
57
Parameter Bar Code Scanning
58
Beep on Decode
59
Direct Decode Indicator
60
Beeper Volume
61
Beeper Tone
62
Beeper Duration
63
Suppress Power Up Beeps
63
Decode Pager Motor (DS4308-HC and DS4308-XD)
64
Decode Pager Motor Duration
64
Night Mode (DS4308-HC Only)
66
Low Power Mode
68
Time Delay to Low Power Mode
69
Hand-Held Trigger Mode
71
Hands-Free Mode
72
Presentation Performance Mode
73
Hands-Free/Hand-Held Auto Switching (DS4308P Only)
74
Hand-Held Decode Aiming Pattern
75
Hands-Free Decode Aiming Pattern
76
Hands-Free Motionless Timeout (DS4308P Only)
76
Motion Detect Range (DS4308P Only)
77
Picklist Mode
78
Continuous Bar Code Read
79
Unique Bar Code Reporting
79
Decode Session Timeout
80
Timeout Between Decodes, Same Symbol
80
Timeout Between Decodes, Different Symbols
81
Fuzzy 1D Processing
81
Decode Mirror Images (Data Matrix Only)
82
Mobile Phone/Display Mode
83
PDF Prioritization
84
PDF Prioritization Timeout
84
Presentation Mode Field of View
85
Decoding Illumination
85
Post Decode Illumination (DS4308P Only)
86
Illumination Brightness
87
Low Light Scene Detection
88
Motion Tolerance (Hand-Held Trigger Modes Only)
89
Movement Sensitivity (DS4308P Only)
90
Object Detection Method (DS4308P Only)
91
Miscellaneous Scanner Parameters
92
Add an Enter Key
92
Transmit Code ID Character
93
Prefix/Suffix Values
94
Scan Data Transmission Format
95
FN1 Substitution Values
96
Transmit “No Read” Message
97
Unsolicited Heartbeat Interval
98
Dump Scanner Parameters
99
Imaging Preferences
101
Introduction
101
Scanning Sequence Examples
102
Errors While Scanning
102
Imaging Preferences Parameter Defaults
102
Imaging Preferences
104
Operational Modes
104
Image Capture Illumination
105
Image Capture Autoexposure
105
Fixed Exposure
106
Fixed Gain
106
Gain/Exposure Priority for Snapshot Mode
107
Snapshot Mode Timeout
108
Snapshot Aiming Pattern
109
Silence Operational Mode Changes
109
Image Cropping
110
Crop to Pixel Addresses
111
Image Size (Number of Pixels)
112
Image Brightness (Target White)
113
JPEG Image Options
113
JPEG Target File Size
114
JPEG Quality and Size Value
114
Image Enhancement
115
Image File Format Selector
116
Image Rotation
117
Bits Per Pixel
118
Signature Capture
119
Signature Capture File Format Selector
120
Signature Capture Bits Per Pixel
121
Signature Capture Width
122
Signature Capture Height
122
Signature Capture JPEG Quality
122
Video Mode Format Selector
123
Video View Finder
123
Target Video Frame Size
124
Video View Finder Image Size
124
USB Interface
125
Introduction
125
Connecting a USB Interface
126
USB Parameter Defaults
128
USB Host Parameters
129
USB Device Type
129
Symbol Native API (SNAPI) Status Handshaking
131
USB Keystroke Delay
131
USB CAPS Lock Override
132
USB Ignore Unknown Characters
132
USB Convert Unknown to Code 39
133
Emulate Keypad
133
Emulate Keypad with Leading Zero
134
Quick Keypad Emulation
134
USB Keyboard FN 1 Substitution
135
Function Key Mapping
135
Simulated Caps Lock
136
Convert Case
136
USB Static CDC
137
Direct I/O Beep
137
TGCS (IBM) USB Beep Directive
138
TGCS (IBM) USB Bar Code Configuration Directive
138
USB Polling Interval
139
USB Fast HID
140
TGCS (IBM) USB Specification Version
141
ASCII Character Set for USB
142
SSI Interface
153
Introduction
153
Communications
153
SSI Transactions
155
General Data Transactions
155
Transfer of Decode Data
156
Communication Summary
157
RTS/CTS Lines
157
ACK/NAK Option
157
Number of Data Bits
157
Serial Response Time-out
157
Retries
157
Baud Rate, Stop Bits, Parity, Response Time-out, ACK/NAK Handshake
158
Errors
158
Things to Remember When Using SSI Communication
158
Using Time Delay to Low Power Mode with SSI
159
Encapsulation of RSM Commands/Responses over SSI
160
Command Structure
160
Response Structure
160
Example Transaction
161
Simple Serial Interface Default Parameters
162
SSI Host Parameters
163
Select SSI Host
163
Baud Rate
164
Parity
165
Check Parity
166
Stop Bits
166
Software Handshaking
167
Host RTS Line State
168
Decode Data Packet Format
168
Host Serial Response Time-out
169
Host Character Time-out
170
Multipacket Option
171
Interpacket Delay
172
Event Reporting
173
Decode Event
173
Boot Up Event
174
Parameter Event
174
RS-232 Interface
175
Introduction
175
Connecting an RS-232 Interface
176
RS-232 Parameter Defaults
177
RS-232 Host Parameters
178
RS-232 Host Types
181
Baud Rate
183
Parity
184
Stop Bit Select
185
Data Bits
185
Check Receive Errors
186
Hardware Handshaking
186
Software Handshaking
188
Host Serial Response Time-out
190
RTS Line State
191
Beep on <BEL>
191
Intercharacter Delay
192
Nixdorf Beep/LED Options
193
Ignore Unknown Characters
193
ASCII Character Set for RS-232
194
IBM 468X / 469X Interface
199
Introduction
199
Connecting to an IBM 468X/469X Host
200
IBM Parameter Defaults
201
IBM 468X/469X Host Parameters
202
Port Address
202
Convert Unknown to Code 39
203
Ignore Beep Directive
203
Ignore Bar Code Configuration Directive
204
Keyboard Wedge Interface
205
Introduction
205
Connecting a Keyboard Wedge Interface
206
Keyboard Wedge Parameter Defaults
207
Keyboard Wedge Host Parameters
208
Keyboard Wedge Host Types
208
Ignore Unknown Characters
208
Keystroke Delay
209
Intra-Keystroke Delay
209
Alternate Numeric Keypad Emulation
210
Quick Keypad Emulation
210
Simulated Caps Lock
211
Caps Lock Override
211
Convert Wedge Case
212
Function Key Mapping
212
FN1 Substitution
213
Send Make and Break
213
Keyboard Maps
214
ASCII Character Set for Keyboard Wedge
215
Symbologies
225
Introduction
225
Scanning Sequence Examples
225
Errors While Scanning
226
Symbology Parameter Defaults
226
Enable/Disable All Code Types
232
UPC/EAN
233
Enable/Disable UPC-A
233
Enable/Disable UPC-E
233
Enable/Disable UPC-E1
234
Enable/Disable EAN-8/JAN-8
234
Enable/Disable EAN-13/JAN-13
235
Enable/Disable Bookland EAN
235
Decode UPC/EAN/JAN Supplementals
236
User-Programmable Supplementals
239
UPC/EAN/JAN Supplemental Redundancy
240
UPC/EAN/JAN Supplemental AIM ID Format
241
UPC Reduced Quiet Zone
242
Transmit UPC-A Check Digit
242
Transmit UPC-E Check Digit
243
Transmit UPC-E1 Check Digit
243
UPC-A Preamble
244
UPC-E Preamble
245
UPC-E1 Preamble
246
Convert UPC-E to UPC-A
247
Convert UPC-E1 to UPC-A
247
EAN-8/JAN-8 Extend
248
Bookland ISBN Format
248
UCC Coupon Extended Code
249
Coupon Report
249
ISSN EAN
250
Code 128
251
Enable/Disable Code 128
251
Set Lengths for Code 128
251
Enable/Disable GS1-128 (formerly UCC/EAN-128)
253
Enable/Disable ISBT 128
253
ISBT Concatenation
254
Check ISBT Table
255
ISBT Concatenation Redundancy
255
Code 128 Security Level
256
Code 128 Reduced Quiet Zone
257
Ignore Code 128 <FNC4>
257
Code 39
258
Enable/Disable Code 39
258
Enable/Disable Trioptic Code 39
258
Convert Code 39 to Code 32
259
Code 32 Prefix
259
Set Lengths for Code 39
260
Code 39 Check Digit Verification
261
Transmit Code 39 Check Digit
261
Code 39 Full ASCII Conversion
262
Code 39 Security Level
263
Code 39 Reduced Quiet Zone
264
Code 93
265
Enable/Disable Code 93
265
Set Lengths for Code 93
265
Code 11
267
Code 11
267
Set Lengths for Code 11
267
Code 11 Check Digit Verification
269
Transmit Code 11 Check Digits
270
Interleaved 2 of 5 (ITF)
271
Enable/Disable Interleaved 2 of 5
271
Set Lengths for Interleaved 2 of 5
271
I 2 of 5 Check Digit Verification
273
Transmit I 2 of 5 Check Digit
274
Convert I 2 of 5 to EAN-13
274
I 2 of 5 Security Level
275
I 2 of 5 Reduced Quiet Zone
276
Discrete 2 of 5 (DTF)
277
Enable/Disable Discrete 2 of 5
277
Set Lengths for Discrete 2 of 5
277
Codabar (NW - 7)
279
Enable/Disable Codabar
279
Set Lengths for Codabar
279
CLSI Editing
281
NOTIS Editing
281
Codabar Upper or Lower Case Start/Stop Characters Detection
282
MSI
283
Enable/Disable MSI
283
Set Lengths for MSI
283
MSI Check Digits
285
Transmit MSI Check Digit(s)
285
MSI Check Digit Algorithm
286
Chinese 2 of 5
287
Enable/Disable Chinese 2 of 5
287
Matrix 2 of 5
288
Enable/Disable Matrix 2 of 5
288
Set Lengths for Matrix 2 of 5
288
Matrix 2 of 5 Check Digit
290
Transmit Matrix 2 of 5 Check Digit
290
Korean 3 of 5
291
Enable/Disable Korean 3 of 5
291
Inverse 1D
292
GS1 DataBar
293
GS1 DataBar-14
293
GS1 DataBar Limited
293
GS1 DataBar Expanded
294
Convert GS1 DataBar to UPC/EAN
294
GS1 DataBar Limited Security Level
295
Composite
296
Composite CC-C
296
Composite CC-A/B
296
Composite TLC-39
297
UPC Composite Mode
297
Composite Beep Mode
298
GS1-128 Emulation Mode for UCC/EAN Composite Codes
298
2D Symbologies
299
Enable/Disable PDF417
299
Enable/Disable MicroPDF417
299
Code 128 Emulation
300
Data Matrix
301
Data Matrix Inverse
301
GS1 Data Matrix
302
Maxicode
302
QR Code
303
GS1 QR
303
MicroQR
304
Aztec
305
Aztec Inverse
305
Han Xin
306
Han Xin Inverse
306
Postal Codes
307
US Postnet
307
US Planet
307
Transmit US Postal Check Digit
308
UK Postal
308
Transmit UK Postal Check Digit
309
Japan Postal
309
Australia Post
310
Australia Post Format
311
Netherlands KIX Code
312
USPS 4CB/One Code/Intelligent Mail
312
UPU FICS Postal
313
Mailmark
313
Symbology-Specific Security Levels
314
Redundancy Level
314
Security Level
316
1D Quiet Zone Level
317
Intercharacter Gap Size
318
Report Version
318
Macro PDF Features
319
Flush Macro Buffer
319
Abort Macro PDF Entry
319
Intelligent Document Capture
321
Introduction
321
The IDC Process
321
Bar Code Acceptance Test
322
Capture Region Determination
322
Image Post Processing
323
Data Transmission
323
PC Application and Programming Support
323
Parameters
324
IDC Operating Mode
325
IDC Symbology
326
IDC X Coordinate
327
IDC Y Coordinate
327
IDC Width
328
IDC Height
328
IDC Aspect
329
IDC File Format Selector
329
IDC Bits Per Pixel
330
IDC JPEG Quality
330
IDC Find Box Outline
331
IDC Minimum Text Length
331
IDC Maximum Text Length
332
IDC Captured Image Brighten
332
IDC Captured Image Sharpen
333
IDC Border Type
334
IDC Delay Time
335
IDC Zoom Limit
335
IDC Maximum Rotation
336
Quick Start
337
Sample IDC Setup
337
IDC Demonstrations
338
Other Suggestions
339
Quick Start Form
339
OCR Programming
341
Introduction
341
OCR Parameter Defaults
342
OCR Programming Parameters
343
Enable/Disable OCR-A
343
OCR-A Variant
343
Enable/Disable OCR-B
345
OCR-B Variant
346
Enable/Disable MICR E13B
349
Enable/Disable US Currency Serial Number
350
OCR Orientation
350
OCR Lines
352
OCR Minimum Characters
352
OCR Maximum Characters
353
OCR Subset
353
OCR Quiet Zone
354
OCR Bright Illumination
354
OCR Template
355
OCR Check Digit Modulus
364
OCR Check Digit Multiplier
365
OCR Check Digit Validation
366
Inverse OCR
371
Driver’s License Set Up (DS4308-DL)
373
Introduction
373
Driver’s License Parsing
374
Parsing Driver’s License Data Fields (Embedded Driver's License Parsing)
375
Embedded Driver's License Parsing Criteria - Code Type
375
Driver’s License Parse Field Bar Codes
376
AAMVA Parse Field Bar Codes
379
User Preferences
389
Set Default Parameter
389
Output Gender as M or F
389
Date Format
390
Send Keystroke (Control Characters and Keyboard Characters)
392
Parsing Rule Example
411
Embedded Driver's License Parsing ADF Example
415
123Scan2
417
Introduction
417
Communication with 123Scan2
417
123Scan2 Requirements
418
Scanner SDK, Other Software Tools, and Videos
418
Advanced Data Formatting
419
Introduction
419
Standard Default Parameters
421
Country Codes
435
Introduction
435
USB and Keyboard Wedge Country Keyboard Types (Country Codes)
436
Country Code Pages
451
Introduction
451
Country Code Page Defaults
451
Country Code Page Bar Codes
455
CKJ Decode Control
465
Introduction
465
CJK Control Parameters
466
Unicode Output Control
466
CJK Output Method to Windows Host
467
Non-CJK UTF Bar Code Output
469
Unicode/CJK Decode Setup with Windows Host
471
Setting Up the Windows Registry Table for Unicode Universal Output
471
Adding CJK IME on Windows
471
Selecting the Simplified Chinese Input Method on the Host
472
Selecting the Traditional Chinese Input Method on the Host
473
Programming Reference
475
Symbol Code Identifiers
475
AIM Code Identifiers
477
Sample Bar Codes
483
Code 39
483
UPC/EAN
483
UPC-A, 100%
483
EAN-13, 100%
484
Code 128
484
Interleaved 2 of 5
484
GS1 DataBar-14
485
PDF417
485
Data Matrix
485
Maxicode
485
QR Code
486
US Postnet
486
UK Postal
486
Numeric Bar Codes
487
Numeric Bar Codes
487
Cancel
488
ASCII Character Sets
489
Communication Protocol Functionality
501
Functionality Supported via Communication (Cable) Interface
501
Signature Capture Code
503
Introduction
503
Code Structure
503
Signature Capture Area
503
CapCode Pattern Structure
504
Start / Stop Patterns
504
Dimensions
505
Data Format
505
Additional Capabilities
506
Signature Boxes
506
Index
507
Other manuals for Zebra DS4308
Quick Start Guide
20 pages
Reference Guide
436 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Zebra DS4308 and is the answer not in the manual?
Ask a question
Zebra DS4308 Specifications
General
Brand
Zebra
Model
DS4308
Category
Barcode Reader
Language
English
Related product manuals
Zebra DS457 Series
462 pages
Zebra DS6878
14 pages
Zebra DS8178
24 pages
Zebra DS2278
22 pages
Zebra DS9908
19 pages
Zebra DS6707
2 pages
Zebra DS3678-ER
4 pages
Zebra Symbol DS7708
36 pages
Zebra LS1203
2 pages
Zebra LI3608
19 pages
Zebra MP7000
210 pages
Zebra Symbol LI4278
2 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
