14 - 44 DS4308/DS4308P Digital Scanner Product Reference Guide

Then, in order to limit the full name to 15 characters, create the following ADF rule:

For a license belonging to Michael Williams, the parsed data is Williams, Michael and Williams, Micha after

applying the previous ADF rule.

Begin New Rule

Criterion: Parsed Driver's License

Action: Send Next 15 Characters

Save Rule
