Parameters 195
02.15 EFB MAIN CW
Internal Control Word of the drive received through
the embedded fieldbus interface.
- / Pb
0x00000000...
0xFFFFFFFF
Embedded fieldbus control word. 1 = 1
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Name Value Information Log. Par.
(continued)
9 JOGGING
1**
1 Activate jogging function 1.
OR
–
0 Jogging function 1 disabled.
10 JOGGING
2**
1 Activate jogging function 2.
OR
–
0 Jogging function 2 disabled.
11 REMOTE
CMD
1 Embedded fieldbus control enabled. – –
0 Embedded fieldbus control disabled.
12 RAMP
OUT 0
1 Force output of Ramp Function Generator to
zero. The drive ramps to a stop (current and
DC voltage limits are in force).
––
0 No action.
13 RAMP
HOLD
1 Halt ramping (Ramp Function Generator output
held).
––
0 No action.
14 RAMP IN 0 1 Force Ramp Function Generator input to zero.
––
0 No action.
15 RESERVED
16 REQ
STARTINH
1 Activate start inhibit.
––
0 No start inhibit.
17 LOCAL
CTL
1 Request local control for Control Word.
Used when the drive is controlled through PC
tool or panel or through local fieldbus.
• Local fieldbus: Transfer to fieldbus local
control (control through embedded fieldbus
Control Word or reference). Embedded
fieldbus steals the control.
• Panel or PC tool: Transfer to local control.
––
0 Request external control.
18 FBLOCAL
REF
1 Request fieldbus local control.
––
0 No fieldbus local control.
19...
26
RESERVED
27 NOT USED
28...
31
CW
B28...B31
Freely programmable control bits.
** Internally used for evacuation and inspection mode operation.
