Parameters 277
91.19 ENDAT MAX CALC
Selects the maximum encoder calculation time for an
EnDat encoder.
Note: This parameter needs to be set only when an
EnDat encoder is used in the continuous mode, that
is EnDat encoder without incremental sin/cos signals
(supported only as encoder). The EnDat encoder is
selected by setting parameter 91.02 ABS ENC
INTERF to EnDat.
50 ms /
UINT32
10 us 10 microseconds. 0
100 us 100 microseconds. 1
1 ms 1 millisecond. 2
50 ms 50 milliseconds. 3
91.20 ENDAT CLOCK
FREQ
Selects the encoder clock frequency for an EnDat
encoder.
Note: This parameter needs to be set only when an
EnDat encoder is used in the continuous mode, that
is EnDat encoder without incremental sin/cos signals
(supported only as encoder). The EnDat encoder is
selected by setting parameter 91.02 ABS ENC
INTERF to EnDat.
4 MHz /
enum
1 MHz 1 Mega Hertz 0
2 MHz 2 Mega Hertz 1
4 MHz 4 Mega Hertz 2
8 MHz 8 Mega Hertz 3
92
92 RESOLVER
CONF
Resolver configuration; used when parameter 90.01
ENCODER SEL is set to FEN-21 RES.
92.01 RESOLV
POLEPAIRS
Selects the number of pole pairs. 1 / UINT32
1…32 Number of pole pairs. 1 = 1 / -
92.02
EXC SIGNAL
AMPL
Defines the amplitude of the excitation signal. 4.0 Vrms /
UINT32
4.0…12.0 Vrms Excitation signal amplitude. 10 = 1 Vrms
/ -
92.03
EXC SIGNAL
FREQ
Defines the frequency of the excitation signal. 1 kHz /
UINT32
1…20 kHz
Excitation signal frequency. 1 = 1 kHz / -
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
