5.5.1 Auto zero
Auto zero supplies an offset which brings the raw baseline signal down to its most sensitive range. An
offset voltage setting that is out of range will set an indicator “alarm in status tab” which will trigger
an amp board software error alarm as well.
Table 5-3: Auto zero
Available from configuration
5.5.2 Component min/max
There is only one TCF required for min/max detector signal integration. All timings are relative to the
time offset.
IMPORTANT NOTE: The sequence offset + the Time offset + the gate value must be > 0 < the
cycle time or 14400 (whichever is smaller).
Start Of Baseline Gate: Begin Time
Start Of Baseline Gate: End Time
End Of Baseline Gate: Begin Time
End Of Baseline Gate: End Time
Start Of Integration Gate: Begin Time
Start Of Integration Gate: End Time
End Of Integration Gate: Begin Time
End Of Integration Gate: End Time
Positive, Negative, Tangent, Calculated
5.5.3 Component RT (EZ Peak)
Table 5-5: Component RT (EZ Peak)
Available from configuration
Available from configuration
Positive, Negative, Tangent, Calculated
5.5.4 Digital input check
Table 5-6: Digital input check
Available from configuration
Ignore, Report, Skip, Abort
