ABB PGC5000 Generation 2 - Analysis Error Messages

56 | PGC5000 GEN 2 | 892 J006 MNAH
14. Fill in the information completely.
15. Select the Add New icon.
16. Select TCF-Method Scope.
17. Select Stream Step.
18. Verify and accept by pressing the Accept button.
19. Fill in the Stream Step information.
20. Save the new analysis to Analysis Config. The Analysis button must be selected when saving.
21. Select the Save As icon to save as a new analysis.
22. Name and save to Analysis Config for immediate use and/or to Analysis Library for future use.
IMPORTANT NOTE: The Analysis must be saved to Analysis Config before it can be added to a
schedule.
An analysis can be modified after it is saved. Select the object to modify, make the changes and save
the analysis.
4.5.5 Analysis error messages
The following error messages will display in the message box at the bottom of the display if an error is
found in the analysis prior to the SBC sending the method to the oven.
Message
Issue / Fix
Analysis not found (e.g.:
Name mismatch)
An Analysis has a trailing space on the end of name that has gone
undetected. One example: Remove space at end of Analysis Name.
TCF is outside Method
A TCF non-End of Analysis script precedes the start of the first Method
defined in the Analysis.
Component TCF - Begin
crest time > 0
A Component TCF has a Crest Begin time offset that is less than zero.
Component TCF - Begin
time >= End time
A Component TCF cannot have a Crest Begin time offset greater than or
equal to its Crest End time offset.
Component TCF: 0 length
Component Name
A Component TCF cannot have an empty Component Name.
Bad oven address for
[DeviceName]
For a given TCF, the associated oven name could not be found in the
device lookup collection.
(Method's oven =
[Oven_Id]) != (TCF
[Sbst].[Node]
.[Type].[Chan])
Analysis has a Method assigned to one oven containing a TCF referring to
a device in another oven.
Component TCF: 0 length
Detector Name
A Component TCF cannot have an empty Detector name.
Non Sequence/TCF after
DoNext/SkipNext
Conditional TCF types must be followed by a legitimate TCF type (e.g.:
Not a Method or a Sequence).
DoNextIf is the last TCF in
Analysis
A Do Next TCF type cannot be the last TCF in an Analysis.
DoNextIf TCF precedes
Component TCF
A Do Next If TCF cannot precede Component TCF.
DoNextIf TCF precedes
DoNextIf TCF
A Do Next If TCF cannot precede another Do Next If TCF.
DoNextIf TCF precedes
TcfSkipNextIf
A Do Next If TCF cannot precede a Skip Next If TCF.
DoNextIf TCF precedes
StreamStep Tcf
A Do Next If TCF cannot precede Stream Step TCF.
DoNextIf TCF precedes
UnknownPeak TCF
A Do Next If TCF cannot precede an Unknown Peak TCF type.
Duplicate Component found
in same Method
A Component with the same Component Name was found in the same
Method.
Component TCF - End crest
time < 0
A Component TCF has a Crest End time offset less than zero.
[Num] Component TCFs,
exceeds max
spec:[MaxNum]
Too many Components were specified in the Analysis.
