Figure 4-18: Graphic Editor/Tabular Editor Map
4.5.2 Tabular editor subtab
The Analysis>Tabular Editor subtab is used to display and edit analytical data (see Figure 4-19).
Figure 4-19: Analysis>Tabular Editor subtab
Legend: Analysis>Tabular Editor subtab
ID
Description
1
Action icons: Create, Add, Delete or Save objects
2
Function select buttons: User-created Analysis objects
3
Editing area: Used to display and edit selected object
Refer to section 5.5 for a complete list of TCFs and their functions.
