Calibration Review
AEROSET
®
Customer Training Guide 6-23
94858-103 — July 2003
Viewing the Previous Calibration Curve
To compare the current calibration curve data with the previous
calibration curve data, perform the following steps.
1. Select the button on the lower right-hand corner of the
Calibration Information area of the ASSAY STATUS screen.
2. The data from the previous calibration curve are displayed in the
Abs and Factor areas. Both the previous and the current calibration
curve graphs are displayed. The date and time the previous
calibration was performed is displayed in the lower right-hand
corner of the Calibration Information area. The previous calibration
curve and the date and time performed text are gray. The current
calibration is blue.
NOTE: The Conc area displays currently configured
values from the Calibrator/Control screen.
3. To return to the current calibration data, select the button or
the button on the lower right-hand corner of the Calibration
Information area of the ASSAY STATUS screen.
NOTE: If a current calibration curve is flagged with the
EXP Calibration Error Code, the curve reverts to a
previous status as soon as there is a current calibration
curve without an error code. A current calibration curve
with any other error code, e.g., FAC or MON, does not
revert to a previous status.
