MODULE 1: SYSTEM TOUR
1-14 AEROSET
®
Customer Training Guide
94858-103 — July 2003
Figure 1.7: View Behind the Front-Right Door
Behind the Front-Right Door
Component Description
Wash Solution Pump Dilutes and supplies Alkaline and Acid
Wash Solutions to the Cuvette Washer.
Bulk Solutions The onboard supply of ICT™ Reference
Solution, Alkaline Wash Solution, and Acid
Wash Solution are placed on the platforms
that will generate an Error Message when
the minimum level is reached.
Acid Wash Solution
Alkaline Wash Solution
ICT Reference Solution
125669
Wash Solution Pump
To Next Page
