ADPRO FastTrace - Firewall Configuration; Table 1: Firewall Ports

Installation and User Manual ADPRO FastTrace by Xtralis
26 Doc 11168_12
7. Go to the Connection menu and select the Installer Menu option to display the
FastTrace's User Settings menu.
8. Change Site Details to the new Site ID, Password and Network Address values.
9. Save all changes when exiting the User Settings menu.
10. Reset Switch 7 to the OFF position and power cycle the unit.
The FastTrace will now operate with the new Site ID, Password and Network Address.
2.14 Firewall Configuration
If the FastTrace unit is connected via a firewall, the following table describes the destination port
allocation for the VideoCentral PC and FastTrace uit. Source ports are randomly chosen. The
control of connections should be done using IP addresses and destination ports.
Table 1: Firewall Ports
Destination Ports on VideoCentral Destination Ports on FastTrace
UDP 15000-15200 UDP 15000-15005
TCP 15001-15007 TCP Any port
