The Duress option is designed to be used with silent panic alarms and will cause a Live and
Quad alarm to be sent to VideoCentral. The Live alarm enables an event to be quickly displayed
at the CMS and the Quad alarm ensures that video is captured at the instant the panic alarm is
operated.
4.3.14 Presidium Inputs
The Presidium Inputs option enables the configuration of video outputs from a Presidium
Intelligent Video System to the FastTrace video inputs.
Note: At least one Presidium Input must be configured. If there are no inputs configured,
the following Presidium system alarms will not work at the FastTrace:
- Presidium Operational
- Tamper alert
- Over Temperature
- Communication to Presidium Lost
- Communication to Presidium Resumed
- Presidium Fault
Note: When connecting a FastTrace to a Presidium, each FastTrace video input must be
directly connected to a Presidium video output. Hence, if the Presidium has 20
channels, a 20 channel FastTrace is required to operate all 20 channels.
Select the Presidium Input number from the displayed list. The status of an Presidium Input is
shown by a small icon to the left of the channel number.
• A Presidium Input is unallocated when no name is shown next to the number.
Figure 82: Unallocated Icon
•The Connect button is used to enable an Alarm Input. A green tick is shown and details can
be modified.
To disable the use of an Alarm Input, the Disconnect button is used and a red cross is shown.
For example, set Disconnect if maintenance is being performed in that area or the sensor is
being replaced.
