ADPRO FastTrace by Xtralis Installation and User Manual
Doc 11168_12 61
Figure 64: Ethernet Settings
IP Address for this Unit
Factory Default 192.168.1.1
The IP Address is used to identify the FastTrace device as a TCP/IP network node. Each
ADPRO Transmitter monitored from the same installation of VideoCentral requires a unique IP
(Internet Protocol) address. The address is divided into four parts separated by a (.), each part
with a decimal range value from 0 to 255.
The following address ranges are invalid:
• 0.xxx.xxx.xxx
• 127.xxx.xxx
• 224-239.xxx.xxx.xxx
• 240-255.xxx.xxx.xxx
• xxx.xxx.xxx.0
• xxx.xxx.xxx.255
• 192.168.10.xxx
Caution: Changing the IP address may mean you can no longer connect to the FastTrace.
Caution: FastTrace can use two different types of interfaces, Ethernet and serial RS232, to
communicate with VideoCentral via an intermediate network. Each of the
communications interfaces on FastTrace has an IP address associated with it
(FastTrace has three IP addresses, one for each of the two serial RS232 interfaces
and one for the Ethernet interface).
Each FastTrace must have unique IP addresses for each communications interface.
This will require management by the Monitoring Stations to ensure all FastTrace
units that communicate with the Monitoring Station have unique IP addresses.
For more information, please refer to Tech-Tip - Unique IP Address Requirements,
available on the website: www.xtralis.com/adpro.
