ADPRO FastTrace by Xtralis Installation and User Manual
Doc 11168_12 87
Control Output Settings
When the Configure button is used, the following settings can be made.
Control Output Name
Option: 16 characters maximum.
Enter the 16 character name to associate with this output. The name can be displayed when
viewing video from a camera input associated with this control output.
Default State
Option: Normally Open, Normally Closed
Default: Normally Open
Defines the state of the control output when it is not being driven by an alarm condition or
controlled remotely.
When set for ‘normally closed’, the control output is shorted to ground via the output transistor.
Manual Operation
The control outputs can either be operated by an operator at VideoCentral or linked to an alarm
condition. Select this box if the VideoCentral operator is to control the output.
Note that this option must be set to allow remote users access to the control output function.
Disconnect Operation
Option: Reset, Latch
Default: Reset
Defines the operational state of the control output after a user has disconnected from the
FastTrace.
•the Reset option returns the output to the condition defined by the Default State.
•the Latch option causes the control output to remain in its current (operated) condition.
4.3.16 Audio
The Audio menu configures the FastTrace audio channel features.
FastTrace supports combined video and audio operation over communication links that have a
minimum data throughput of 14.4 kbps. This provides simultaneous video and audio operation,
with an audio bandwidth of 300 Hz-3 kHz, over standard public switched telephone networks
(PSTN) as well as high speed digital networks.
Note: Although FastTrace always passes audio at the maximum possible bandwidth, the
overall audio quality will ultimately depend on the quality of the microphones and
speakers connected to the FastTrace and the level of background noise in the
environment. Tests should always be performed with the desired audio equipment
to obtain an understanding of the audio performance.
