U511 User’s Manual Parameters
Version 1.1 Aerotech, Inc. 4-79
4.10.8. “AUX fault output bit” (0, 1-8)
Parameter x54 is used to specify an output bit (1-8) that is activated (set low) if a
programmable "AUX output” fault condition (see x58) is met. Deactivate this feature by
entering 0. Refer to Hardware Details chapter for technical details about the eight TTL
outputs of the UNIDEX 511 including output lines, pin numbers, and electrical
characteristics.
Parameter x54 can have a value that ranges from 0 to 8. These values are explained in
Table 4-60.
Table 4-60. Settings for Parameter x54
Param # Axis # Values and Descriptions
x54 1, 2, 3, 4 0 disabled
1 - output bit 0 is activated on associated AUX output faults
(default for axis 1)
2 - output bit 1 is activated on associated AUX output faults
3 - output bit 2 is activated on associated AUX output faults
4 - output bit 3 is activated on associated AUX output faults
5 - output bit 4 is activated on associated AUX output faults
6 - output bit 5 is activated on associated AUX output faults
7 - output bit 6 is activated on associated AUX output faults
8 - output bit 7 is activated on associated AUX output faults
A reset of the UNIDEX 511 sets all output bits high (deactivated).
x54
E
