Aerotech UNIDEX 511 - Table 10-5. UNIDEX 511;Opto 22 Connection Information

Technical Details U511 User’s Manual
10-6 Aerotech, Inc. Version 1.1
Table 10-5. UNIDEX 511/Opto 22 Connection Information
Interface Cable
Assembly
(model OPC)
PB8, PB16A, PB16C and PB24 Board
Opto
Interface
(P5)
Control
Connection (edge
connector on Opto
board)
Module
Position
Connection
Description
Type of
Module
Field Connection
(barrier strip)
49 49 +5 V int
supply

47 47 0 Out 0 output 1 and 2

45 45 1 Out 1 output 3 and 4

43 43 2 Out 2 output 5 and 6 PB8

41 41 3 Out 3 output 7 and 8

39 39 4 Out 4 output 9 and 10

37 37 5 Out 5 output 11 and 12

35 35 6 Out 6 output 13 and 14

33 33 7 Out 7 output 15 and 16
↓
31 31 8 In 0 input 17 and 18

29 29 9 In 1 input 19 and 20 PB

27 27 10 In 2 input 21 and 22 16A

25 25 11 In 3 input 23 and 24 and

23 23 12 In 4 input 25 and 26 16C

21 21 13 In 5 input 27 and 28

19 19 14 In 6 input 29 and 30

17 17 15 In 7 input 31 and 32
↓
15 15 16 In 8 input 33 and 34

13 13 17 In 9 input 35 and 36

11 11 18 In 10 input 37 and 38 PB24
9 9 19 In 11 input 39 and 40

