U511 User’s Manual The User Interface
Version 1.1 Aerotech, Inc. 3-11
This screen has four selectable functions, one of which leads to other screens. These
functions are described below:
F1 ASCII Opens the ASCII utility so users can enter or change the name of
the file.
F3 Return Return will return the user to the program being edited.
F4 Save Save will store the file being edited and exit edit mode.
F5 NoSave NoSave will exit edit mode without saving the file.
3.4.3. The ASCII Utility
This screen enables users to build commands or file names, including non-numerical
characters, using only the keys on the front panel. If the user has a keyboard, the
commands or file names can be typed in directly.
Use of the ASCII utility is only necessary when a keyboard is unavailable.
The ASCII utility appears in many forms. An example screen is shown in Figure 3-12.
This screen is for editing a file name and would appear after the user pressed “ASCII”
(F1) in the “Save File As:” screen. The important features on this page are the two lines of
ASCII characters and the functions at the bottom of the page.
The data entry point is automatically placed to the right of “Save File As:” The cursor is
situated on the first line of the ASCII characters. To insert an ASCII character, use the
function keys at the bottom of the screen or the arrow keys on the front panel to move the
cursor to the desired character, then press ENTER. The selected character will appear at
the entry point. This can be repeated until the command or filename is built.
F1 F2 F3 F4
Save File As: TEST1.PRG
!"#$%&’()*+,-./0123456789:;<=>?
@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_
TabLeft TabRight HOME END QUIT
Figure 3-12. The ASCII Utility
