U511 User’s Manual The User Interface
Version 1.1 Aerotech, Inc. 3-7
This screen has five selectable functions that are described below:
F1 Auto/Single The Auto/Single key determines if the program is to run
automatically (Auto) or by executing one block at a time (Single).
F2 Cycle Cycle is used to start and step through programs.
F3 Stop Stop is used to stop a running program. All axis motion will
terminate and the program will be unloaded from memory.
F4 Display Display allows the user to monitor the running program. Executing
program lines can be displayed on the screen by pushing this key.
This slows down block processing time of the U511 and is only
recommended for program debugging.
F5 Quit Quit will exit the Run Program screen and will prompt the user if a
program is running. A program is allowed to run in the background
after pressing this key.
3.4.2. Program Menu: the Edit Submenu
Pressing the F2 key in the Program screen brings up the Edit submenu. The Edit submenu
is a series of screens. First, the Edit File screen, which is used to select the file to be
edited, appears. Refer to Figure 3-7. To select a file, use the up and down arrow keys or
the PgDown/PgUp function to move the cursor. The selected file is shown in reverse
video. The selected file name or “untitled” in the case of a new file, appears in the first
line. Press ENTER to begin editing.
F1 F2 F3 F4
F
5
Edit File: TEST1.PRG
TEST1.PRG 11 10/10/97 09:4
6
P
M
TEST5.PRG 31 08/21/97 09:5
0
P
M
TEST2.PRG 13 10/10/97 09:4
5
P
M
PgDown *.* Last New Q
u
i
t
Figure 3-7. Edit File Screen, Edit File Submenu
There are five selectable functions on the Edit File screen:
F1 PgDown/PgUp This function moves one screen down or up through the list of
displayed files. Toggle between PgDown and PgUp by
reversing the direction with the cursor keys.
F2 *.*/*.prg This function toggles between displaying all files (*.*) or just
program files (*.prg). The function key label shows the
extension that will be selected when F2 is pressed.
F3 Last This function recalls the last selected file or program.
F4 New New generates a new program.
F5 Quit The Quit function exits or quits this operation.
