4.8. Page 8: Motors and Feedback
The UNIDEX 511 utilizes several parameter settings for configuration based on the motor
and drive type being used. This section provides an introduction to motor and feedback
configuration. The motor and feedback configuration parameters are explained in detail
in the sections that follow.
The parameters that are used to configure motor and feedback functions of the U511
depend on the type of motor that is being used. A list of motor types (Stepper, AC
Brushless, and DC Servo), their related parameters, and default values are shown in
Table 4-39.
Table 4-39. Motor Feedback Parameters
Param # Description Step AC
Brushless
DC
Servo
Default
Value(s)
x38 “Position channel” á á á 1, 2, 3, 4
x39 “Velocity channel” N/A á á 0
x40 “Position setup code” á á á 3
x41 “Velocity setup code” N/A á á 3
x42 “Amplifier type” á á á 0
x43 “Commutation cycles/rev” N/A á N/A 4
x44 “Feedback steps/rev” á á á 4000
x45 “Commutation phase offset” (degrees) N/A á N/A 0
x46 “Stepper high current %” (0-100%) á N/A N/A 70
x47 “Stepper low current %” (0-100%) á N/A N/A 35
x63 “Microstepping resolution” (machine
steps)
á N/A N/A 4000
x64 “Stepper correction” (y/n) á N/A N/A Yes
x65 “Stepper correction speed” á N/A N/A 1.0
x66 “Base speed” (machine steps/ms) N/A á N/A 0
x67 “Base speed advance” (0-359 degrees) N/A á N/A 0
x68 “Phase speed” (machine steps/ms) N/A á N/A 0
x69 “Phase speed advance” (0-359 degrees) N/A á N/A 0
x79 “Primary DAC offset” (mV) á á á 0
x80 “Secondary DAC offset” (mV) á á á 0
x82 “Encoder factor” N/A á á 0
