Parameters U511 User’s Manual
4-22 Aerotech, Inc. Version 1.1
Table 4-14. Settings for Parameter x15
Param # Axis # Description
115 1 Yes - Axis calibration is enabled for axis 1
No - Axis calibration is not enabled for axis 1 (default)
215 2 Yes - Axis calibration is enabled for axis 2
No - Axis calibration is not enabled for axis 2 (default)
315 3 Yes - Axis calibration is enabled for axis 3
No - Axis calibration is not enabled for axis 3 (default)
415 4 Yes - Axis calibration is enabled for axis 4
No - Axis calibration is not enabled for axis 4 (default)
;***** Comments *****************************************
; The :START and :END statements surround the calibration information.
; First non-comment line is axis number (1-4). Second non-comment line
; is the sample distance (in machine steps) that the axis must travel before
; the next sequential correction datum is added to the current position to
; correct it. Correction data is space-separated and may be entered on
; multiple lines.
;***************** SAMPLE.CAL ************************
:START ;start axis call block
1 ;axis number (1,2,3, or 4)
1000 ;sample distance in machine steps
;(>256)
1 2 3 5 7 9 12 14 16 14 10 8 5 2 1 0 ;absolute machine step correction
;data
:END ;end axis call block
:START ;next axis to be calibrated
2 ;axis number (1, 2, 3, or 4)
1000 ;sample distance in machine steps
1 1 1 2 4 2 5 10 8 8 7 6 6 2 1 1 ;absolute machine step correction
;data
:END ;end axis call block
::
::
Figure 4-1. Sample ASCII Calibration File
