Aerotech UNIDEX 511 - Figure 3-5. Load Program Screen; Figure 3-6. Running Program Screen

The User Interface U511 User’s Manual
3-6 Aerotech, Inc. Version 1.1
F1 F2
F
3
F
4
F5
Load Program: TEST1.PRG
TEST1.PRG 11 10/10/97 09:46PM
TEST5.PRG 31 08/21/97 09:50PM
TEST2.PRG 13 10/10/97 09:45PM
PgDown *.* Quit
Figure 3-5. Load Program Screen
There are three selectable functions under the Load Program screen. These are described
below:
F1 PgDown/PgUp This function moves one screen down or up through the list of
displayed files. Toggle between PgDown and PgUp by
reversing the direction with the cursor keys.
F2 *.*/*.prg This function toggles between displaying all files (*.*) or just
program files (*.prg). The function key label shows the
extension that will be selected when F2 is pressed.
F5 Quit The Quit function exits or quits this operation and returns to
the Program screen.
After a program has been selected and loaded (when ENTER is pressed), the Running
Program screen is displayed. Refer to Figure 3-6. This screen is used to start, control, and
monitor programs. The program and line being executed are listed in the first line of the
screen. Axis position and status information appears in the center of the screen. The axis
position information is automatically updated as the program runs.
F1 F2
F
3
F
4
F5
Running Progra
m
:
T
E
S
T
1
.
P
R
G
Line:1
X0.
0
0
0
m
m
E
n
a
b
led
Y0.
0
0
0
m
m
E
n
a
b
led
Z0.
0
0
0
m
m
E
n
a
b
led
U0.
0
0
0
m
m
E
n
a
b
led
Auto Cycle
S
t
o
p
D
i
s
p
lay Quit
Figure 3-6. Running Program Screen
