U511 User’s Manual Getting Started
Version 1.1 Aerotech, Inc. 2-1
CHAPTER 2: GETTING STARTED
In This Section:
• Introduction................................................................2-1
• Unpacking the UNIDEX 511 Unit .............................2-1
• UNIDEX 511 Setup Flowchart...................................2-2
• Installing Cables and Wiring......................................2-3
• Software Configuration Considerations .....................2-4
• Special Startup Considerations...................................2-4
• Enabling and Moving an Axis....................................2-7
• Internal System Wiring...............................................2-7
2.1. Introduction
This chapter steps the operator through unpacking the U511, connecting cables, and
verifying basic functionality.
2.2. Unpacking the UNIDEX 511 Unit
Before unpacking any components, visually inspect the containers of the U511 system for
any evidence of shipping damage. If any such damage exists, notify the shipping carrier
immediately.
Remove the packing list from the UNIDEX 511 container. Make certain that the items
listed on the packing slip are contained within the package. The following items should
be found in every UNIDEX 511 system:
• The UNIDEX 511 Motion Controller User’s Manual
• Windows -compatible, 32 bit U511 utility software
• UNIDEX 511 packing slip (listing products shipped with the order)
The following list of additional items may be included with the UNIDEX 511 system,
depending on the options and accessories that have been specified:
• Motor connector cables
• JBV or JI joystick and cable
• Handwheel assembly and cable
• I/O cables or Opto 22 boards
• RS-232 cable
