Aerotech UNIDEX 511 - Figure 3-30. Terminal Page; Table 3-8. Active Components of the Terminal Page

U511 User’s Manual The User Interface
Version 1.1 Aerotech, Inc. 3-27
F1 F2 F3 F4
F
5
Page 8 Terminal
Com 1 Tran:_
Rec :
Com 2 Tran:
Rec :
GPIB Tran:
Rec :
Back Next
Q
u
it
Figure 3-30. Terminal Page
Table 3-8. Active Components of the Terminal Page
Field Status Description
Tran: Sends and displays characters transmitted to the host system from
the selected port. Pressing ENTER will send the EOS (end of
string) character.
Rec: Displays characters received from any/all ports. Nonprintable
characters will be displayed in hexadecimal format and in
brackets.
