U511 User’s Manual The User Interface
Version 1.1 Aerotech, Inc. 3-3
3.3. Power-up Screen
When the U511 is first powered-up, the screen provides information on the U511
software version and amount of free memory. It also reveals whether remote mode is
enabled. In addition, this screen lists a Main menu of five major U511 functions, any of
which can be activated by pressing one of the function keys (F1-F5) below the screen.
The Power-up screen is shown in Figure 3-2.
F1 F2 F3 F4
Unidex 511 - Software Version 1.01
Free Memory 48226 (bytes)
Program Setup Diag Tune MDI
Figure 3-2. Power-Up Screen
The following is a description of the five selectable functions (F1-F5) on the Power-up
screen:
F1 Program The Program function allows the user to run programs, edit files,
copy and delete files, and digitize programs.
F2 Setup The Setup function provides the user the ability to check, change,
and save parameters.
F3 Diag The Diagnostics function allows the user to check status, fault
conditions, and communication operations.
F4 Tune The Tune function allows the user to tune, check or change tuning
parameters, and save tuning parameters.
F5 MDI The MDI function allows the user to operate the joystick, enter
individual program commands, and perform jog operations.
Activating one of these functions opens other screens with additional function choices on
them. These function submenus either carry out some related operation or lead, in turn, to
more screens. This series of menus and submenus is illustrated in Figure 3-3. Each
submenu is related somehow to the function that activated it. For example, the File
function under the Program menu leads to a screen called File Operations where users can
copy or delete files. The menus under Setup and Diagnostics shown in Figure 3-3 are not
selectable functions but “pages” of information that can be accessed with the “Next”
function.
In the sections that follow, screens are discussed in a top down fashion with the first Main
menu function discussed under a major section heading, and all the submenus beneath it
discussed in subsections under the major heading. In each section, the screen is described
first and then the actions of the corresponding functions are listed.
