U511 User’s Manual Parameters
Version 1.1 Aerotech, Inc. 4-7
4.2. Page 1: System Configuration
Page 1 parameters primarily allow the user to indicate which files will be run after reset.
Configuration parameters for the optional PSO-PC board are also included, as are
parameters for setting the joystick deadband and center position. These and other
parameters are explained in detail in this section.
4.2.1. “Auto enable axes”
Parameter 600 selects the axes that are automatically enabled on power up. Axes X, Y, Z,
and/or U can be selected. To deselect an axis, simply delete the entry leaving the field
blank. No axes enabled is the default setting.
4.2.2. “Auto run program”
Parameter 601 selects a program to be loaded and executed in auto mode after power up.
The default setting is a blank, meaning no program is to be executed. To deselect a file,
simply delete it, leaving the field blank.
4.2.3. “Axis calibration file”
Parameter 602 is the “Axis calibration file” loaded to the DSP during reset. The default
setting is blank; meaning no calibration file is to be used. To deselect a file, simply delete
it, leaving the field blank.
4.2.4. “Parameter file”
Parameter 603 specifies the file containing parameters 0-99 and axis parameters 100-199,
200-299, 300-399, and 400-499. The default file is U511.PRM. If the UNIDEX 511 is
factory configured by Aerotech, this field will contain a file name of the form
123456.PRM. The six-digit number is the Aerotech reference number for the system.
4.2.5. “Firmware file”
Parameter 604 is the file loaded to the DSP during reset. The default file is A:\U511.JWP.
4.2.6. “M-code file”
Parameter 605 is a file containing "M"-code definitions that can be accessed from any
program. The default setting is a blank; meaning no program is available. To deselect a
file, simply delete it, leaving the field blank.
600
601
602
603
604
605
