The User Interface U511 User’s Manual
3-12 Aerotech, Inc. Version 1.1
The five function keys on the ASCII utility are described below:
F1 TabLeft Moves the cursor to the left five characters in the ASCII list.
F2 TabRight Moves the cursor to the right five characters in the ASCII list.
F3 Home Moves the cursor to the beginning of the ASCII character list.
F4 End Moves the cursor to the end of the ASCII character list.
F5 Quit (or Back) Registers the changes and returns to the original screen with
the command or file name inserted.
3.4.4. Program Menu: the File Submenu
Upon choosing the F3 key in the Program screen, the user enters the file operations mode.
The File Operations screen (Figure 3-13) is used to copy and delete files. Move the cursor
to the desired file (it will appear in reverse video), then select Copy (F4) to make a copy
of a file, or Del (F3) to erase the file. The F2 function toggles between displaying all files
(*.*) or just program files (*.prg). The function key label shows the extension that will be
selected when F2 is pressed.
F1 F2
F
3
F
4
F5
File O
p
e
r
a
t
i
o
n
s
TEST1.PRG
1
1
1
0
/
1
0
/
97 09:46PM
TEST5.PRG
3
1
0
8
/
2
1
/
97 09:50PM
TEST2.PRG
1
3
1
0
/
1
0
/
97 09:45PM
PgDown *.*
D
e
l
C
o
p
y Quit
Figure 3-13. File Operations Screen
3.4.5. Program Menu: The Digitize Submenu
The Digitize function allows the user to edit a file and use the joystick to generate
positioning commands in the program. This function may be used to generate linear,
circular (clockwise or counterclockwise), or spline move commands.
When Digitize is selected from the Program submenu, an Edit File screen, similar to the
one in the Edit submenu is displayed. Refer back to Figure 3-7. The user is required to
input the file to be digitized. Once the file is selected or new file is chosen, the Program
Editor screen for the Digitize submenu will be displayed. See Figure 3-14. This screen
functions identically to the Program Editor screen of the Edit submenu except that the
Copy/Paste function is replaced with a “Digit” function. This function enables the joystick
and allows the user to select the type of command generated.
