Agilent Technologies 1220 Infinity II LC User Manual

100 1220 Infinity II LC System User Manual
6 Injection System Description
Manual Injector
Manual Injector
The Agilent 1220 Infinity II LC manual injector uses a Rheodyne, 6-port
sample injection valve (5067-4202). Sample is loaded into the external 20 μL
sample loop through the injection port at the front of the valve. The valve has a
PEEK™ injection seal. A make-before-break passage in the stator ensures flow
is not interrupted when the valve is switched between the INJECT and LOAD
positions, and back again.
Figure 28 Rheodyne 6-port sample injection valve
The Injection Seal
The manual injector is supplied with a PEEK™ injection seal as standard.
/RDGSRVLWLRQ
,QMHFWSRVLWLRQ
