Agilent Technologies 1220 Infinity II LC User Manual

64 1220 Infinity II LC System User Manual
4 LAN Configuration
Initialization mode selection
Initialization mode selection
The following initialization (init) modes are selectable:
Using Stored
When initialization mode Using Stored is selected, the parameters are taken
from the non-volatile memory of the module. The TCP/IP connection will be
established using these parameters. The parameters were configured
previously by one of the described methods.
Figure 11 Using Stored (Principle)
Table 11 Initialization Mode Switches
SW 6SW 7SW 8Init Mode
OFF ON OFF Using Stored
OFF ON ON Using Default
ON OFF OFF
DHCP
1
1
Requires firmware B.06.40 or above. Modules without LAN on board, see G1369C LAN Interface Card
1RQ9RODWLOH
5$0
6WRUHG
3DUDPHWHU
$FWLYH
3DUDPHWHU
