Agilent Technologies 1220 Infinity II LC User Manual

1220 Infinity II LC System User Manual 109
Injection System Description
6
Autosampler
Transport Assembly
The transport unit comprises an X-axis slide (left-right motion), a Z-axis arm
(up-down motion), and a gripper assembly (rotation and vial-gripping).
Figure 35 Transport Assembly
Table 21 Injection valve technical data
Standard
Motor type 4 V, 1.2 A stepper motor
Seal material Vespel™ (Tefzel™ available)
Number of ports 6
Switching time < 150 ms
;PRWRU
;D[LV
=D[LV
7KHWDD[LV
7KHWDPRWRU
*ULSSHUPRWRU
*ULSSHU
=PRWRU
)OH[ERDUG
