1220 Infinity II LC System User Manual 53
Installation
3
Install a Column
Install a Column
When Installing or changing columns
Tools required p/n Description
8710-0510 Wrench open 1/4 — 5/16 inch
Flexible wrench
Parts required Description
Ordered Column
Preparations Remove the restriction capillary (if installed), see “Remove the Restriction Capillary” on page 51.
1
Open both front covers.
2
Connect the column inlet capillary to the injection valve
(port 6).
To Next Page
