1220 Infinity II LC System User Manual 67
LAN Configuration
4
Dynamic Host Configuration Protocol (DHCP)
Setup (DHCP)
The DHCP functionality is available on all Agilent HPLC modules with on-board LAN
Interface or LAN Interface Card G1369C, and “B”-firmware (B.06.40 or above) or modules
with "D"-firmware. All modules should use latest firmware from the same set.
1 Note the MAC address of the LAN interface (provided with G1369C LAN
Interface Card or Main Board). This MAC address is on a label on the card
or at the rear of the main board, e.g. 0030d3177321.
On the Instant Pilot the MAC address can be found under Details in the LAN
section.
Figure 14 LAN Setting on Instant Pilot
