1220 Infinity II LC System User Manual 19
Site Requirements and Specifications
2
Physical Specifications
Physical Specifications
Table 1 Physical Specifications
Type Specification Comments
Weight 30 kg (66 lbs)
G4294B:
43 kg (94 lbs)
Dimensions
(height × width × depth)
640 × 370 × 420 mm
(25.2 × 14.6 × 16.5 inches)
G4294B:
640×370×485 mm
(25.2×14.6×19.1 inches)
Line voltage 100 – 240 V~, ± 10 % Wide-ranging
capability
Line frequency 50 or 60 Hz, ± 5 %
Power consumption 240 VA / 210 W / 717 BTU Maximum
Ambient operating
temperature
4–55 °C (39–131 °F)
Ambient non-operating
temperature
-40 – 70 °C (-40 – 158 °F)
Humidity < 95 % r.h. at 40 °C (104 °F) Non-condensing
Operating altitude Up to 2000 m (6562 ft)
Non-operating altitude Up to 4600 m (15092 ft) For storing the module
Safety standards: IEC, CSA,
UL
Installation category II, Pollution degree 2 For indoor use only.
