268 1220 Infinity II LC System User Manual
11
Maintenance and Repair
Manual Injector
Exchanging the Injection Valve Seal
When Poor injection-volume reproducibility
Leaking injection valve
Tools required Description
Hex key, 9/64 inch
(supplied in the tool kit)
Parts required p/n Description
5068-0082 Rotor seal, PEEK
1
Loosen the three stator screws. Remove the stator head.
2
Remove the stator ring.
