Maintenance and Repair
11
Manual Injector
3
Remove the rotor seal. 4 Install the new rotor seal.
5 Install the stator ring. Ensure the pin in the stator ring is
aligned with the hole in the valve body.
6 Install the stator head onto the valve.
