Agilent Technologies 1220 Infinity II LC User Manual

356 1220 Infinity II LC System User Manual
13 Upgrading the 1220 Infinity II LC
Oven Upgrade
Oven Upgrade
Parts required p/n Description
G4297A 1220 Infinity Oven Kit
Software required Lab Advisor Software
Preparations Switch off the instrument.
1 Remove the lower front cover. 2 Disconnect the column and remove it (“Remove a
Column” on page 55).
3 Remove the leak drain tube. 4 Press the knurled portion at either side of the column
tray inwards (1) and remove the column tray (2).
Leak drain
tube
(2)
(1)
(1)
