116 1220 Infinity II LC System User Manual
7
Column Oven Description
Column Oven
Column Oven
The column oven is based on a resistor heater matt with two thermal sensors
to provide constant temperature in the whole column area. A built-in over
temperature cut off fuse inhibits overheating.
The inner volume of the oven capillary is 6 μL.
Maximum column length is 25 cm (10 inch).
Operational range is at least 10 °C up to 80 °C, max. specified flow rate is
5mL/min at 60°C.
Never operate the column oven with open front cover, to ensure a correct column
temperature always operate with closed front cover. The counterpart of the oven isolation
is fixed at the inner side of the front cover.
