Agilent Technologies 1220 Infinity II LC User Manual

1220 Infinity II LC System User Manual 289
Maintenance and Repair
11
Autosampler
3
Rotate the gripper arm slowly from left to right and apply
a gentle pressure to the paper clip. The clip will engage
on an internal catch and the rotation of the arm will be
blocked.
4 Hold the paper clip in place, press the gripper release
button and rotate the gripper arm to the right.
5 The gripper arm will come off. 6 Replace the gripper arm by holding the paper clip in
place, pushing the gripper arm into the holder and
rotating the gripper arm to the left.
Next Steps:
7 On completion of this procedure: Install the front cover.
8 Turn the power to the Instrument ON.
