Agilent Technologies 1220 Infinity II LC User Manual

316 1220 Infinity II LC System User Manual
11 Maintenance and Repair
Diode Array Detector (DAD)
9
Insert the capillary into the hole between fixing screw
and the inlet fitting.
10 The capillary lays in the grove and should be tied around
the body (in the grove) 5 times.
11 Insert the fixing screw, so that the capillary cannot leave
the grove.
12 Carefully insert the I.D. tag into the new heat exchanger.
Shown is the default orientation. See Note at the
beginning of this section.
6FUHZ
,QOHWFDSLOODU\
ZLWKKHDW
H[FKDQJHU
