Agilent Technologies 6850 Series - Valve actuator assembly, continued

Inlets and valves
6850
6850
Released: April 2004 6850 Series Gas Chromatograph Service Procedures 54
Valve actuator assembly, continued
Description Part no. Qty.
1. Dowel pin 1480-0017 1
2. Socket head screw, M4 x 8-mm 0515-0153 3
3. Link 19325-80010 1
4. Piston rod 19325-20650 1
5. Teflon tubing, 1/8-inch od x 42-inch
for actuators
0890-0746 1
6. Hose fitting
0100-1205 2
7. O-ring, 0.239-inch id
0905-0103 1
8. Actuator cylinder
19325-20630 1
9. Piston
19325-20640 2
10. O-ring, 1.046-inch id
0905-0463 1
11. O-ring, 1.176-inch id
0905-1405 1
12. Cylinder end cap
19325-20680 1
13. Elbow fitting
0100-1220 1
