Detectors

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 151

PMT and bracket assemblies

Description Part no. Qty.

1. Heater/Sensor assembly G1535-60610 1

2. Photomultiplier Tube (PMT)

G1535-80050 –

3. O-ring 0905-1099 –

4. PM tube and housing assembly 19256-60510 1

5. Main bracket

G1535-00010 1

6. Chimney, back G1535-00020 1

7. Chimney, front G1535-00030 1

Filters

Sulfur mode (not shown) 19256-80000

Phosphorus mode (not shown) 19256-80010
