Inlets and valves

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 48

Direct Valve-to-Column Connector Kit

Direct-tube assembly

Liner tool

18900-20850

Liner for 320 µm

Liner for 530 µm

320 µm column union

0100-1527

530 µm column union

0100-1515

1/16-inch Vespel/graphite ferrules

SS nut, 1/16-inch

0100-1511

1/8-inch to 1/16-inch

reducing union, 0100-1542

columns, 0100-1513

columns, 0100-1514

0100-1512
