Inlets and valves

6850

Released: April 2004 6850 Series Gas Chromatograph Service Procedures 45

Valves

Sampling valves

Valve heated block

G2630-20710

Washer

3050-1977

Sample line weldment

G2630-80500

Heater/sensor assembly

G1544-61140

Gas sampling valve

Screw

0515-0655

Gas or liquid sampling valve: see Table 1-1

Gas sample loop: see Table 1-1

Continued
